產品介紹 Product Introduction 警 告 Warning

12合1太陽能液壓動力百戰天龍結合太陽能動力與液壓動力設計而成，每一個設 1.本玩具內含小物件，請勿讓三歲以下孩童取得，
計都是仿生模型，逼真活潑。說明書中提供給您12種不同玩法，如攀爬猴子、張 以免放入口中造成窒息。
口的大鱷魚和霸王龍、正在行走的鴕鳥、正瞪大眼睛用爪子攻擊的蝎子、大象、 Choking hazard - Small parts. Not for children
堆高機、馬車等多種變化。結合太陽能與液壓兩種力量，這群百戰天龍機器人可 under 3 years.
以活潑逗趣的動起來，給孩子們的更多互動趣味。12合1太陽能液壓動力百戰 2.兒童使用剪切工具時，請家長指導使用方式，
天龍只要太陽和水，無需電池就能啟動。透過模型的組裝成型及每一種生物的運 並請在家長監督下使用，以免發生意外。
動方式觀察，讓孩子更加認識大自然界中動物的特徵，例如大象的長鼻和無齒翼 Adult supervision is recommended when
龍的翅膀。動手做更可以培養孩子們的邏輯能力，透過功能的實現與觀察天 children use scissors.
龍們如何運作，領略到更多科學奧秘。 3.為避免嬰兒或兒童產生窒息的危險，請於拆
The solar and hydraulic powered robot can be transformed into twelve different animals 卸後立即將塑膠袋銷毀或遠離嬰兒及兒童。
and mechanic robots. Every model features multitude of functional and biomimicry movements and To avoid danger of suffocation, keep the plastic
unique modeling. The user can change from climbing monkey>mouth opening crocodile bag away from babies and children.
and T-Rex->running ostrich>claws attacking scorpion>zigzagging buggy and more. Combining these
two power, these adorable robots can move easily and also provide great interaction with kids.
12 In 1 solar hydraulic powered robot is designed to have children learn the benefit of alternative energy 自備工具 Tools You May Need
and basic concept of these technolo-gies. This product is powered by the sun and water, there are no
batteries required. The robot can move in direct sunlight and allows children to play with it outdoors and
also encourage them to explore the world.
The modeling and the movement of the models are referred to natural animals which include its most
面紙
obvious characteristic such as elephant's trunk and pteranodon's wing. While the children are playing with 斜口鉗 Cup & Water Screwdriver Tissue Paper
水 & 杯子
十字起子
them, they can realize the function of these characteristic and observe how they work. For more, the Diagonal Cutter
children can use their own infinite imagination to create a brand new species.
部分零件含有銳利的邊緣及尖角
零件清單 Mechanical Parts List ！ Product contains functional edges and sharp points.
P1 馬達端子組 Motor With Connectors P2 太陽能板彈簧端子組 Solar Panel With Springs P3 軟管(15cm) Soft Tube (15cm)

請勿將電線連接到其他電源或牆上插座 1 pc 1 pc 1 pc
Don't connect the wires to the mains.
P4 小齒輪(黃色) P5 六角軸齒輪組 P6 齒輪(紅色) P7 齒輪(綠色) P8 自攻螺絲 P9 泡棉 Sponge
Gear(Red)
Gear(Green)
Tapping Screw
Gear With Shaft
Pinion Gear(yellow)
1 pc 1 pc 1 pc 2 pc 2 pc 2 pc
P10 圓軸 Round Shaft P11 棉繩 Rope P12 活塞帽(紅色) P13 分隔紙板 Cardboard
Cap(Red)
divider

1 pc 1 pc 2 pc
P14 液壓油包 Oil Bag 140mm

安裝軟管時請勿碰觸到油
Do not touch the oil while fitting the soft tube.
1 pc 350mm

塑膠模型零件 Plastic Parts

請依照組裝步驟將所需的零件剪下，以免組裝時造成零件混淆 E
Cut the plastic parts when they are required. Do not cut them in advance.
A B C D

小技巧提醒: 請將毛邊剪切乾淨，以免產生間隙導致運作不良 Tip:cut off the burrs before assembly

毛邊 毛邊
burr burr

毛邊
burr
